24 hours led module testing
72 hours led screen testing
Application :
Specification :
LED Module | Pixel Pitch | P4 mm |
Pixel configuration | SMD 2121 | |
Pixel density | 62,500 pixels/m2 | |
LED lamp | Kinglight /Nation Star | |
IC | ICN 2153/FM 6168/FM 6353 | |
Scan | 1/16 S | |
Module size | 256*128 mm | |
LED Cabinet | Cabinet Thickness | 80 mm |
Cabinet Color(Front/Back) | Black,Grey (you can choose as you like) | |
Maintenance Mode | Front /back | |
Cabinet Material | Die -casting aluminum | |
Cabinet Dimension | 512X512 X80 mm | |
Power supply | G-energy / MEANWELL | |
Parameter | Brightness | 800-1300cd/m2 |
Refresh Rate | ≥3840HZ | |
Best viewing distance | 4-30m | |
Viewing angle | 140°W ; 140 °H | |
IP grade | IP 43 | |
Life span | 100,000 hours | |
Working Voltage | AC 220V/110V±10% | |
Input Power Frequency | 50/60Hz | |
Defect Rate | ≤0.0001 | |
Average power consumption | 350 W / m2 | |
Max power consumption | 600 W / m2 | |
Operating Temperature | –30℃~+60℃ 10%~95%RH | |
Signal Input | HDMI, DVI, VGA, RF, S-Video, RGB, RGBHV, YUV, YC&Composition, etc. | |
Control Distance | 120 m (no repeating); Optical fiber transmission: 500m- 10km | |
Systems Operating Platform | WINDOWS(WIN2000/ WINXP/WIN7/WIN8/WIN10) |
